Kingtronics Kt Aluminum Electrolytic Capacitor Brief Introduction

Kingtronics produce and sell a wide variety of Aluminum Electrolytic Capacitors with long life, low Impedance and excellent performance options. Kingtronics best Aluminum Electrolytic Capacitors include Axial Type, Radial Type, Snap-in Type, Screw Type and Lug Type and SMD Chip Type. Operating temperatures up to 150°C are available. Applications include automotive power, industrial LED lighting, telecom infrastructure and so on. Please refer to below product list of Aluminum Electrolytic Capacitors.

Kingtronics Kt Aluminum Electrolytic Capacitor Product List Get-Quote

Polymer Aluminum Solid Electrolytic Capacitors
Kingtronics P/N Load Life Temperatures Characteristic Datasheet
GKT-AS 2000H 105°C Standard Low ESR ↓ Download PDF
GKT-AR 2000H 105°C Super Low ESR ↓ Download PDF
GKT-AU 2000H 125°C High Ripple Current ↓ Download PDF
GKT-AX 2000H 125°C High Temperature ↓ Download PDF
GKT-AP 2000H 105°C Low ESR ↓ Download PDF
GKT-AJ 3000H 105°C Super low ESR ↓ Download PDF
GKT-AW 3000H 105°C Low ESR ↓ Download PDF
GKT-AK 5000H 105°C long life ↓ Download PDF
GKT-AY 5000H 105°C high voltage,long life ↓ Download PDF
GKT-AH 5000H 105°C SMD type,miniaturized ↓ Download PDF
Aluminum Electrolytic Capacitors - Radial Type
Kingtronics P/N Load Life Temperatures Characteristic Datasheet
GKT-GS 2000H 85°C Super Miniaturized ↓ Download PDF
GKT-GT 2000H 105°C High Temperature ↓ Download PDF
GKT-GH 2000H 105°C Low Impedance ↓ Download PDF
GKT-GL 5000H 105°C Long Life ↓ Download PDF
GKT-GD 3000H~6000H 105°C Miniaturized, long life ↓ Download PDF
GKT-GE 5000H 130°C Long life ↓ Download PDF
GKT-GF 5000H 105°C Miniaturized,high stability ↓ Download PDF
GKT-GQ 4000H~10000H 105°C Long life, Miniature ↓ Download PDF
GKT-GR 3000H~6000H 105°C Long life,High frequency ↓ Download PDF
GKT-GU 3000H 105°C Long life, Miniature ↓ Download PDF
GKT-GZ 6000H-10000H 105°C Extremely long life ↓ Download PDF
GKT-GN 1000H 105°C Non-Polarized ↓ Download PDF
GKT-GW 2000H 105°C Extra Lower Impedance ↓ Download PDF
Aluminum Electrolytic Capacitors - SMD Type
Kingtronics P/N Load Life Temperatures Characteristic Datasheet
GKT-VA 2000H 85°C Standard ↓ Download PDF
GKT-VT 1000H~2000H 105°C Standard ↓ Download PDF
GKT-VC 2000H 105°C Low Leakage Current ↓ Download PDF
GKT-VE 2000H-3000H 105°C Long Life ↓ Download PDF
GKT-VK 2000H-3000H 105°C Extra Lower Impedance ↓ Download PDF
GKT-VL 3000H-5000H 105°C Extra Long Life ↓ Download PDF
GKT-VN 2000H 105°C Bi-polar ↓ Download PDF
GKT-VZ 1000H-2000H 105°C Low Impedance ↓ Download PDF
GKT-VU 3000H 105°C Long Life ↓ Download PDF
GKT-VD 5000H 105°C Long life ↓ Download PDF
GKT-VW 10000H 105°C Long life ↓ Download PDF
GKT-VH 1000H-2000H 125°C Long life ↓ Download PDF
GKT-VF 2000H-5000H 105°C Super Low Impedance ↓ Download PDF
GKT-VR 2000H-3000H 105°C Small Size ↓ Download PDF
GKT-VX 2000H -55°C~ +105°C Small Size ↓ Download PDF
GKT-VY 2000H 105°C Small Size ↓ Download PDF
GKT-VJ 2000H 105°C Small Size ↓ Download PDF


Aluminum Electrolytic Capacitors - Snap-in, Lug and Screw Type
Kingtronics P/N Load Life Temperatures Characteristic Datasheet
GKT-SB 1000H 85°C Snap-in, High Ripple Current ↓ Download PDF
GKT-SS 2000H 85°C Snap-in, High Ripple Current ↓ Download PDF
GKT-ST 2000H 105°C Snap-in, High Ripple Current ↓ Download PDF
GKT-SC 5000H 85°C Snap-in, High Ripple Current ↓ Download PDF
GKT-SD 3000H 105°C Snap-in, High Ripple Current ↓ Download PDF
GKT-CA 2000H 85°C Screw, High Ripple Current ↓ Download PDF
GKT-CB 2000H 105°C Screw, High Ripple Current ↓ Download PDF
GKT-UA 1000H 85°C Lug, Standard product ↓ Download PDF
Aluminum Electrolytic Capacitors - Axial Type
Kingtronics P/N Load Life Temperatures Characteristic Datasheet
GKT-AL 2000H 85°C Low Leakage Current ↓ Download PDF
GKT-AV 2000H 85°C Standard ↓ Download PDF
GKT-AT 1000H 105°C Standard ↓ Download PDF
GKT-AA 1000H 105°C Audio, DF at Max 4% BP ↓ Download PDF
GKT-AM 1000H 105°C Audio, DF at Max 5% BP ↓ Download PDF
GKT-AN 1000H 105°C Audio, DF at Max 10% BP ↓ Download PDF
GKT-AQ 1000H 105°C Audio, DF at Max 10% BP ↓ Download PDF
GKT-AB 2000H 105°C Non-Polarized ↓ Download PDF
GKT-AC 2000H 105°C Bi-Polarized ↓ Download PDF
GKT-AD 1000H 105°C Audio,Standard ↓ Download PDF

Kingtronics Kt Aluminum Electrolytic Capacitor Photos

About Aluminum Electrolytic Capacitors

Aluminum Electrolytic Capacitor usually simply called an electrolytic capacitor (e-cap), is consists of cathode aluminum foil, capacitor paper (electrolytic paper), electrolyte, and an aluminum oxide film, which acts as the dielectric, formed on the anode foil surface.

There are a number of parameters of importance beyond the basic capacitance and capacitive reactance when using electrolytic capacitors. When designing circuits using electrolytic capacitors it is necessary to take these additional parameters into consideration for some designs, and to be aware of them when using electrolytic capacitors.

1, ESR Equivalent series resistance: Electrolytic capacitors are often used in circuits where current levels are relatively high. Also under some circumstances and current sourced from them needs to have a low source impedance, for example when the capacitor is being used in a power supply circuit as a reservoir capacitor. Under these conditions it is necessary to consult the manufacturers datasheets to discover whether the electrolytic capacitor chosen will meet the requirements for the circuit. If the ESR is high, then it will not be able to deliver the required amount of current in the circuit, without a voltage drop resulting from the ESR which will be seen as a source resistance.

2, Frequency response: One of the problems with electrolytic capacitors is that they have a limited frequency response. It is found that their ESR rises with frequency and this generally limits their use to frequencies below about 100 kHz. This is particularly true for large capacitors, and even the smaller electrolytic capacitors should not be relied upon at high frequencies. To gain exact details it is necessary to consult the manufacturers data for a given part.

3, Leakage: Although electrolytic capacitors have much higher levels of capacitance for a given volume than most other capacitor technologies, they can also have a higher level of leakage. This is not a problem for most applications, such as when they are used in power supplies. However under some circumstances they are not suitable. For example they should not be used around the input circuitry of an operational amplifier. Here even a small amount of leakage can cause problems because of the high input impedance levels of the op-amp. It is also worth noting that the levels of leakage are considerably higher in the reverse direction.

4, Ripple current: When using electrolytic capacitors in high current applications such as the reservoir capacitor of a power supply, it is necessary to consider the ripple current it is likely to experience. Capacitors have a maximum ripple current they can supply. Above this they can become too hot which will reduce their life. In extreme cases it can cause the capacitor to fail. Accordingly it is necessary to calculate the expected ripple current and check that it is within the manufacturers maximum ratings.

5, Tolerance: Electrolytic capacitors have a very wide tolerance. Often capacitors may be quoted as -20% and +80%. This is not normally a problem in applications such as decoupling or power supply smoothing, etc. However they should not be used in circuits where the exact value is of importance.
